Ekinex EK-EH2-TP-RW, Pushbutton 6 channels

Produktnummer: 10341288

inkl. mva.

Ekinex FF-serien er essensiell geometri i former, LESS IS MORE. KNX teknologi med brytere, termostater og touchpaneler i et utvalg av plast-, metall- eller Fenix NTM® materialer.

6-fold KNX pushbutton (max. 12 independent functions). Mounting on round, square or rectangular wall box. Power supply via bus. To be used in KNX installations for home and building automation. Bus terminal block, construction-site protection, fixing screws and mounting support included in the delivery. The device has to be to completed with six square rockers and a rectangular frame of the series form or flank (to be ordered separately).

EK-EH2-TP (leds colours: blue / green)
EK-EH2-TP-RW (leds colours: red / white)


  • on/off switching of single loads or groups of loads
  • dimming of lighting devices
  • control of motor drives (for roller shutters, blinds, curtains, etc.)
  • recalling and saving of scenes
  • sending on the bus of values (temperature, etc.)
  • switching to forced functioning (lock)
  • measuring of room temperature through integrated sensor


A detailed description of the parameters can be found in the application manual of the device. Configuration and commissioning require ETS4 or later versions. ETS application program: APEKEH2TP##.knxprod (## = release). Available languages: English, French, German, Italian
