Control4 C4-SDSW240-N, Square Dual Load Wireless Switch

Produktnummer: 10361959

inkl. mva.

Square Dual Load Wireless Switch


This device must be installed in a standard square UK/China-style single-gang wall box and use a single-gang EU faceplate. It cannot be installed in a round EU-style wall box or in multi-gang boxes.

The Control4® Square Dual Load Wireless Switch combines two relays and a configurable keypad for on/off control of up to two loads. The keypad can be configured with two to seven buttons using five different buttons sizes for a total of 38 possible configurations.

Important Note: Faceplates and buttons (color change kits) are not included. Don’t forget to order faceplates and color change kits separately.


  • Provides independent control of up to two different loads.
  • Wireless communication and standard wiring provide easy installation in new construction and retrofit environments.
  • Compatible with a variety of load types including incandescent, halogen, electronic low-voltage (solid state) transformers, magnetic (iron core) low-voltage transformers, fluorescents, compact fluorescents, LEDs, and motors.
  • Continuously measures energy being used by the attached load.
  • Elegant, sophisticated design makes a beautiful addition to any home or business.
  • Custom engraving available to clearly identify each button.
  • Backlit button engraving with programmable color control for easy readability regardless of time of day or light level.
  • Programmable RGB LEDs provide status feedback for lighting and other devices in the system.
  • Configure with two to seven buttons using five different button sizes for a total of 38 possible configurations.
  • Easy reconfiguration means there’s no need to worry about how many buttons will be needed on a specific switch before (or even after) installation.
  • Ships as “neutral” device with no buttons included. Keypad-style button kit and Rocker-style button kits sold separately in a variety of colors (see “Available accessories”).
  • Ambient light sensor automatically adjusts backlight and status LED brightness depending on the light level in the room.
  • Control4® screw-less faceplates sold separately, provide a sleek profile (see “Available accessories”).
  • Installs in standard square (UK/China-style) single-gang wall box.
  • Not compatible with round (EU-style) or UK-style double-gang wall boxes.
